Face Recognition¶
In the Getting Started , we had an overview of the face recognition API. In this section, we shall explore all the functionalities of the API.
Starting DeepStack on Docker¶
Run the command below as it applies to the version you have installed
docker run -e VISION-FACE=True -v localstorage:/datastore -p 80:5000 deepquestai/deepstack
sudo docker run --gpus all -e VISION-FACE=True -v localstorage:/datastore -p 80:5000 deepquestai/deepstack:gpu
deepstack --VISION-FACE True --PORT 80
sudo docker run --runtime nvidia -e VISION-FACE=True -p 80:5000 deepquestai/deepstack:jetpack
sudo docker run -e VISION-FACE=True -p 80:5000 deepquestai/deepstack:arm64
sudo docker run -e VISION-FACE=True -p 80:5000 deepquestai/deepstack:arm64-server
sudo deepstack start "VISION-FACE=True"
Basic Parameters
-e VISION-FACE=True This enables the face recognition APIs.
-v localstorage:/datastore This specifies the local volume where DeepStack will store all data.
-p 80:5000 This makes DeepStack accessible via port 80 of the machine.
Face Registration¶
The face registration endpoint allows you to register pictures of person and associate it with a userid. You can specify multiple pictures per person during registration.
Example
import requests
user_image1 = open("image1.jpg","rb").read()
user_image2 = open("image2.jpg","rb").read()
response = requests.post("http://localhost:80/v1/vision/face/register",
files={"image1":user_image1,"image2":user_image2},data={"userid":"User Name"}).json()
print(response)
const request = require("request")
const fs = require("fs")
run_prediction("image1.jpg","User Name")
function run_prediction(image_path,userid){
image_stream = fs.createReadStream(image_path)
var form = {"image":image_stream,"userid":userid}
request.post({url:"http://localhost:80/v1/vision/face/register", formData:form},function(err,res,body){
response = JSON.parse(body)
console.log(response)
})
}
using System;
using System.IO;
using System.Net.Http;
using System.Threading.Tasks;
namespace app
{
class App {
static HttpClient client = new HttpClient();
public static async Task registerFace(string userid, string image_path){
var request = new MultipartFormDataContent();
var image_data = File.OpenRead(image_path);
request.Add(new StreamContent(image_data),"image1",Path.GetFileName(image_path));
request.Add(new StringContent(userid),"userid");
var output = await client.PostAsync("http://localhost:80/v1/vision/face/register",request);
var jsonString = await output.Content.ReadAsStringAsync();
Console.WriteLine(jsonString);
}
static void Main(string[] args){
registerFace("User Name ","userimage-path").Wait();
}
}
}
Response
{'message': 'face added', 'success': True}
The response above indicates the call was successful. You should always check for the ** success ** status. If there is an error in your request, you will receive a response like
{'error': 'user id not specified', 'success': False}
This indicates that you omitted the userid in your request. If you omitted the image, the response will be
{'error': 'No valid image file found', 'success': False}
Face Recognition¶
The face recognition endpoint detects all faces in an image and returns the userid for each face. Note that the userid was specified during the registration phase. If a new face is encountered, the userid will be unknown.
We shall test this on the image below.
import requests
image_data = open("test-image2.jpg","rb").read()
response = requests.post("http://localhost:80/v1/vision/face/recognize",
files={"image":image_data}).json()
for user in response["predictions"]:
print(user["userid"])
print("Full Response: ",response)
const request = require("request")
const fs = require("fs")
image_stream = fs.createReadStream("test-image2.jpg")
var form = {"image":image_stream}
request.post({url:"http://localhost:80/v1/vision/face/recognize", formData:form},function(err,res,body){
response = JSON.parse(body)
predictions = response["predictions"]
for(var i =0; i < predictions.length; i++){
console.log(predictions[i]["userid"])
}
console.log(response)
})
using System;
using System.IO;
using System.Net.Http;
using System.Threading.Tasks;
using Newtonsoft.Json;
namespace appone
{
class Response {
public bool success {get;set;}
public Face[] predictions {get;set;}
}
class Face {
public string userid {get;set;}
public float confidence {get;set;}
public int y_min {get;set;}
public int x_min {get;set;}
public int y_max {get;set;}
public int x_max {get;set;}
}
class App {
static HttpClient client = new HttpClient();
public static async Task recognizeFace(string image_path){
var request = new MultipartFormDataContent();
var image_data = File.OpenRead(image_path);
request.Add(new StreamContent(image_data),"image",Path.GetFileName(image_path));
var output = await client.PostAsync("http://localhost:80/v1/vision/face/recognize",request);
var jsonString = await output.Content.ReadAsStringAsync();
Response response = JsonConvert.DeserializeObject<Response>(jsonString);
foreach (var user in response.predictions){
Console.WriteLine(user.userid);
}
Console.WriteLine(jsonString);
}
static void Main(string[] args){
recognizeFace("test-image2.jpg").Wait();
}
}
}
Idris Elba
unknown
Full Response: {'success': True, 'predictions': [{'x_min': 215, 'confidence': 0.76965684, 'x_max': 264, 'y_max': 91, 'y_min': 20, 'userid': 'Idris Elba'}, {'x_min': 115, 'confidence': 0, 'x_max': 162, 'y_max': 97, 'y_min': 31, 'userid': 'unknown'}]}
As you can see above, the first face is unknown since we did not previously register her, however, Idris Elba was detected as we registered a picture of him in the previous tutorial. Note also that the full response contains the coordinates of the faces.
Extracting Faces¶
The face coordinates allows you to easily extract the detected faces. Here we shall use PIL to extract the faces and save them
import requests
from PIL import Image
image_data = open("test-image2.jpg","rb").read()
image = Image.open("test-image2.jpg").convert("RGB")
response = requests.post("http://localhost:80/v1/vision/face/recognize",
files={"image":image_data}).json()
for face in response["predictions"]:
userid = face["userid"]
y_max = int(face["y_max"])
y_min = int(face["y_min"])
x_max = int(face["x_max"])
x_min = int(face["x_min"])
cropped = image.crop((x_min,y_min,x_max,y_max))
cropped.save("{}.jpg".format(userid))
const request = require("request")
const fs = require("fs")
const easyimage = require("easyimage")
image_stream = fs.createReadStream("test-image2.jpg")
var form = {"image":image_stream}
request.post({url:"http://localhost:80/v1/vision/face/recognize", formData:form},function(err,res,body){
response = JSON.parse(body)
predictions = response["predictions"]
for(var i =0; i < predictions.length; i++){
pred = predictions[i]
userid = pred["userid"]
y_min = pred["y_min"]
x_min = pred["x_min"]
y_max = pred["y_max"]
x_max = pred["x_max"]
easyimage.crop(
{
src: "test-image2.jpg",
dst: userid+".jpg",
x: x_min,
cropwidth: x_max - x_min,
y: y_min,
cropheight: y_max - y_min,
}
)
}
})
using System;
using System.IO;
using System.Net.Http;
using System.Threading.Tasks;
using Newtonsoft.Json;
using SixLabors.ImageSharp;
using SixLabors.ImageSharp.Processing;
using SixLabors.Primitives;
namespace appone
{
class Response {
public bool success {get;set;}
public Face[] predictions {get;set;}
}
class Face {
public string userid {get;set;}
public float confidence {get;set;}
public int y_min {get;set;}
public int x_min {get;set;}
public int y_max {get;set;}
public int x_max {get;set;}
}
class App {
static HttpClient client = new HttpClient();
public static async Task recognizeFace(string image_path){
var request = new MultipartFormDataContent();
var image_data = File.OpenRead(image_path);
request.Add(new StreamContent(image_data),"image",Path.GetFileName(image_path));
var output = await client.PostAsync("http://localhost:80/v1/vision/face/recognize",request);
var jsonString = await output.Content.ReadAsStringAsync();
Response response = JsonConvert.DeserializeObject<Response>(jsonString);
foreach (var user in response.predictions){
var width = user.x_max - user.x_min;
var height = user.y_max - user.y_min;
var crop_region = new Rectangle(user.x_min,user.y_min,width,height);
using(var image = Image.Load(image_path)){
image.Mutate(x => x
.Crop(crop_region)
);
image.Save(user.userid + ".jpg");
}
}
}
static void Main(string[] args){
recognizeFace("test-image2.jpg").Wait();
}
}
}
Setting Minimum Confidence¶
DeepStack recognizes faces by computing the similarity between the embedding of a new face and the set of embeddings of previously registered faces. By default, the minimum confidence is 0.67. The confidence ranges between 0 and 1. If the similarity for a new face falls below the min_confidence, unknown will be returned.
The min_confidence parameter allows you to increase or reduce the minimum confidence.
We lower the confidence allowed below.
import requests
image_data = open("test-image2.jpg","rb").read()
response = requests.post("http://localhost:80/v1/vision/face/recognize",
files={"image":image_data},data={"min_confidence":0.40}).json()
for user in response["predictions"]:
print(user["userid"])
print("Full Response: ",response)
const request = require("request")
const fs = require("fs")
image_stream = fs.createReadStream("test-image2.jpg")
var form = {"image":image_stream,"min_confidence":0.30}
request.post({url:"http://localhost:80/v1/vision/face/recognize", formData:form},function(err,res,body){
response = JSON.parse(body)
predictions = response["predictions"]
for(var i =0; i < predictions.length; i++){
pred = predictions[i]
console.log(pred["userid"])
}
})
using System;
using System.IO;
using System.Net.Http;
using System.Threading.Tasks;
using Newtonsoft.Json;
namespace appone
{
class Response {
public bool success {get;set;}
public Face[] predictions {get;set;}
}
class Face {
public string userid {get;set;}
public float confidence {get;set;}
public int y_min {get;set;}
public int x_min {get;set;}
public int y_max {get;set;}
public int x_max {get;set;}
}
class App {
static HttpClient client = new HttpClient();
public static async Task recognizeFace(string image_path){
var request = new MultipartFormDataContent();
var image_data = File.OpenRead(image_path);
request.Add(new StreamContent(image_data),"image",Path.GetFileName(image_path));
request.Add(new StringContent("0.30"),"min_confidence");
var output = await client.PostAsync("http://localhost:80/v1/vision/face/recognize",request);
var jsonString = await output.Content.ReadAsStringAsync();
Response response = JsonConvert.DeserializeObject<Response>(jsonString);
foreach (var user in response.predictions){
Console.WriteLine(user.userid);
}
Console.WriteLine(jsonString);
}
static void Main(string[] args){
recognizeFace("test-image2.jpg").Wait();
}
}
}
Idris Elba
Adele
Full Response: {'success': True, 'predictions': [{'userid': 'Idris Elba', 'y_min': 154, 'x_min': 1615, 'x_max': 1983, 'confidence': 0.76965684, 'y_max': 682}, {'userid': 'Adele', 'y_min': 237, 'x_min': 869, 'x_max': 1214, 'confidence': 0.6044803, 'y_max': 732}]}
By reducing the allowed confidence, the system detects the first face as Adele. The lower the confidence, the more likely for the system to make mistakes. When the confidence level is high, mistakes are extremely rare, however, the system may return unknown always if the confidence is too high.
For security related processes such as authentication, set the min_confidence at 0.7 or higher .
Managing Registered Faces¶
The face recognition API allows you to retrieve and delete faces that have been previously registered with DeepStack.
Listing faces
import requests
faces = requests.post("http://localhost:80/v1/vision/face/list").json()
print(faces)
const request = require("request")
request.post("http://localhost:80/v1/vision/face/list",function(err,res,body){
response = JSON.parse(body)
console.log(response)
})
using System;
using System.IO;
using System.Net.Http;
using System.Threading.Tasks;
namespace app
{
class App {
static HttpClient client = new HttpClient();
public static async Task listFaces(){
var output = await client.PostAsync("http://localhost:80/v1/vision/face/list",null);
var jsonString = await output.Content.ReadAsStringAsync();
Console.WriteLine(jsonString);
}
static void Main(string[] args){
listFaces().Wait();
}
}
}
Response
{'success': True, 'faces': ['Tom Cruise', 'Adele', 'Idris Elba', 'Christina Perri']}
Deleting a face
import requests
response = requests.post("http://localhost:80/v1/vision/face/delete",
data={"userid":"Idris Elba"}).json()
print(response)
const request = require("request")
var form = {"userid":"Idris Elba"}
request.post({url:"http://localhost:80/v1/vision/face/delete", formData:form},function(err,res,body){
response = JSON.parse(body)
console.log(response)
})
using System;
using System.IO;
using System.Net.Http;
using System.Threading.Tasks;
namespace app
{
class App {
static HttpClient client = new HttpClient();
public static async Task registerFace(string userid){
var request = new MultipartFormDataContent();
request.Add(new StringContent(userid),"userid");
var output = await client.PostAsync("http://localhost:80/v1/vision/face/delete",request);
var jsonString = await output.Content.ReadAsStringAsync();
Console.WriteLine(jsonString);
}
static void Main(string[] args){
registerFace("Idris Elba").Wait();
}
}
}
Reponse
{'success': True}
Having deleted Idris Elba from our database, we shall now attempt to recognize him in our test image.
import requests
image_data = open("test-image2.jpg","rb").read()
response = requests.post("http://localhost:80/v1/vision/face/recognize",
files={"image":image_data}).json()
for user in response["predictions"]:
print(user["userid"])
const request = require("request")
const fs = require("fs")
image_stream = fs.createReadStream("test-image2.jpg")
var form = {"image":image_stream}
request.post({url:"http://localhost:80/v1/vision/face/recognize", formData:form},function(err,res,body){
response = JSON.parse(body)
predictions = response["predictions"]
for(var i =0; i < predictions.length; i++){
pred = predictions[i]
console.log(pred["userid"])
}
})
using System;
using System.IO;
using System.Net.Http;
using System.Threading.Tasks;
using Newtonsoft.Json;
namespace appone
{
class Response {
public bool success {get;set;}
public Face[] predictions {get;set;}
}
class Face {
public string userid {get;set;}
public float confidence {get;set;}
public int y_min {get;set;}
public int x_min {get;set;}
public int y_max {get;set;}
public int x_max {get;set;}
}
class App {
static HttpClient client = new HttpClient();
public static async Task recognizeFace(string image_path){
var request = new MultipartFormDataContent();
var image_data = File.OpenRead(image_path);
request.Add(new StreamContent(image_data),"image",Path.GetFileName(image_path));
var output = await client.PostAsync("http://localhost:80/v1/vision/face/recognize",request);
var jsonString = await output.Content.ReadAsStringAsync();
Response response = JsonConvert.DeserializeObject<Response>(jsonString);
foreach (var user in response.predictions){
Console.WriteLine(user.userid);
}
}
static void Main(string[] args){
recognizeFace("test-image2.jpg").Wait();
}
}
}
Response
unknown
unknown
Performance¶
DeepStack offers three modes allowing you to tradeoff speed for performance. During startup, you can specify performance mode to be , High , Medium and Low.
The default mode is Medium.
You can specify a different mode during startup as seen below as seen below
docker run -e VISION-FACE=True -e MODE=High -v localstorage:/datastore -p 80:5000 deepquestai/deepstack
sudo docker run --gpus all -e VISION-FACE=True -e MODE=High -v localstorage:/datastore -p 80:5000 deepquestai/deepstack:gpu
deepstack --VISION-FACE True --MODE High --PORT 80
sudo docker run --runtime nvidia -e VISION-FACE=True -e MODE=High -p 80:5000 deepquestai/deepstack:jetpack
Speed Modes are not available on the Raspberry PI Version
